Mean Well DIN rail power supply series TDR-960

Switching power supplies in a slim housing (110mm width) with 960W, a built-in DC OK relay contact, a three-phase input, screw terminals (touch guard) and a parallel function (3+1/3840W). These device...

Mean Well DIN rail power supply series TDR-960

Switching power supplies in a slim housing (110mm width) with 960W, a built-in DC OK relay contact, a three-phase input, screw terminals (touch guard) and a parallel function (3+1/3840W). These devices are suitable for DIN rail mounting, have a fanless design and are protected against overload (auto recovery), overtemperature, overvoltage as well as short circuit. They have a built-in active PFC function and comply with EN62368-1, EN61000-6-2, EN50082-2, EN55032, EN61204-3 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: TDR-960-24 and TDR-960-48.

  • single output
  • output: 960W
  • input voltage: 340 to 550V AC (47 to 63Hz), 480 to 780V DC
  • maximal input inrush current: 60A
  • leakage current: <3,5mA
  • overload protection: 105 to 130%
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -30 to +70°C
  • weight: 2470g
> More
Data Sheet
Showing 1 - 2 of 2 products
  • Product Stock Unit price Volume discounts
  • Mean Well
    TDR-960-24
    210,29 €
    37906 TDR-960-24 TDR-960-24
    210,29 €
    Quantity Unit price
    50 + 204,89 €
    Stock: 2
  • Mean Well
    TDR-960-48
    210,29 €
    37907 TDR-960-48 TDR-960-48
    210,29 €
    Quantity Unit price
    50 + 204,89 €
    Stock: 95
