rated current: 6A

* relay with forcibly guided contacts according to EN50205
* AC or DC coil control with LED status indicator
* 2-, 4- or 6-pole safety relay
* 35 mm rail (EN 60715) mount
* category of protection IP20
* application functional safety i...

rated current: 6A

* relay with forcibly guided contacts according to EN50205
* AC or DC coil control with LED status indicator
* 2-, 4- or 6-pole safety relay
* 35 mm rail (EN 60715) mount
* category of protection IP20
* application functional safety in machine and plant according to EN 13849-1
* contact
* contact material: AgNi
* rated current: 6A
* inrush current, max.:
7S.12._: 15A
7S.14._, 7S.16._: 12A
* rated voltage: 250V AC
* max. switching power AC1: 1500VA
* max. switching power AC15 (230V AC)
7S.12._: 700VA
7S.14._, 7S.16._: 500VA
* max. switching current DC1 (30/110/220V)
7S.12._: 6A/0,6A/0,2A
7S.14._, 7S.16._: 6A/0,6A/0,3A
* min. switching load: 60mW (5V/5mA)
* lifetime mechanical: 10x106 operations
* lifetime electrical: 100x103 operations
* housing: 100,3x78,8x22,5mm
* operating temperature: -40...+70°C
* by Finder
