Hahn PCB transformers

Transformers in a self-extinguishing housing with an EI30 core and 1,3VA. These devices have a low no-load loss (<0,4W) and comply with temperature resistance class Ta 70/F as well as EN61558. They are short circuit proof ...

Hahn PCB transformers

Transformers in a self-extinguishing housing with an EI30 core and 1,3VA. These devices have a low no-load loss (<0,4W) and comply with temperature resistance class Ta 70/F as well as EN61558. They are short circuit proof and suitable for PCB mounting. We offer the type BV EI 307 8011 of this Hahn series.

  • core: EI30
  • output: 1,3VA
  • input voltage: 230V AC (50/60Hz)
  • temperature class: Ta 70/F
  • no-load power loss: <0,4W
  • maximal end temperature (short circuit): 210°C
  • maximal end temperature: 140°C
