Recom LED driver series RACT12

LED drivers in a plastic housing (IP20) with 12W, a constant current, a TRIAC dimmer (phase-cut dimmer), protection class II and a universal input. These devices are suitable for LED lighting applications and are pro...

Recom LED driver series RACT12

LED drivers in a plastic housing (IP20) with 12W, a constant current, a TRIAC dimmer (phase-cut dimmer), protection class II and a universal input. These devices are suitable for LED lighting applications and are protected against overload, overvoltage as well as short circuit. They have screw terminals and comply with EN55015, EN61347-1, EN61347-2-13, IEC61347-1 as well as IEC61347-2-13. We offer the following types of this Recom series: RACT12-350, RACT12-500 and RACT12-700.

  • single output
  • output: 12W
  • input voltage: 198 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 5A
  • withstand voltage I/P-O/P: 3750V AC
  • operating temperature: -20 to +50°C
  • dimensions: 109x40x22mm
  • weight: 70g
