Mean Well LED driver series PWM-60-KN

LED drivers in a plastic case with 60W, a constant voltage, protection class II, a low no-load power consumption (<0,5W) and an integrated KNX control protocol. These devices have a PWM style output to maintain the colour temperature and the brightness as well as a built-in active PFC function and are protected against short circuit, overtemperature, overvoltage as well as overload (auto recovery). They are suitable for LED lighting applications, have a minimum dimming level of 0,5% and comply with EN61347-1, EN61347-2-13, EN55015 as well as EN61000-3-2 class C. The PWM output frequency is adjustable by ETS up to a maximum of 4kHz. We offer the following types of this Mean Well series: PWM-60-12KNX and PWM-60-24KNX.

single output
output: 60W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 50A
overload protection: 108 to 130%
withstand voltage I/P-O/P: 3750V AC
operating temperature: -35 to +85°C
weight: 450g

> More

Data Sheet
