Mean Well power supply series BIC-2200

Bidirectional switching power supplies (AC/DC and DC/AC) in an enclosed housing with 2160W, a fan, a screw terminal, a universal input, a low profile (1U), a built-in remote ON/OFF control, a CAN bus interface (BIC-2200-_CAN) and a parallel function. These devices have a built-in active PFC function and are protected against overload, anti-islanding, overvoltage as well as short circuit. They have a switching time of of 1ms between AC/DC and DC/AC and comply with EN62368-1, EN55032 class B, EN61000-3-2 class A as well as EN61000-3-3. We offer the following types of this Mean Well series: BIC-2200-12, BIC-2200-24, BIC-2200-48, BIC-2200-96, BIC-2200-12CAN, BIC-2200-24CAN, BIC-2200-48CAN and BIC-2200-96CAN.

  • single output
  • output: 2160W
  • input voltage: 180 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 35A
  • leakage current: <2mA
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -30 to +70°C
  • weight: 2900g
> More
Data Sheet
