small housings

* manufacturer: Supertronic

MUGE15
* hand-held enclosure consisting of two shell halves
* lap joint construction
* two lateral guides (stud and bushing) are used to connect both shell halves.
* two cams for self-tapping screws where a printed circuit can be mounted.


MUGE 16
* transmission receipt enclosure for a remote control
* consisting of two shell halves which snap together to connect.
* lap joint construction
* 12V-Battery is required
* the printed circuit is fastened without screws onto a molded stud.
* in the upper section, there is a countersunk keypad.
* a button actuator is included which lies adjacent to an opening for a LED
* the firmly attached plastic button has a stroke of approx. 2mm, e.g. for operating a microswitch which is beneath (not supplied in the delivery)

MUGE 17
* similar to MUGE 15, but with 4 screws composed of stud and bushing placed in the corner to connect both shell halves

MUGE 18
* transmission receipt enclosure for a remote control
* similar to MUGE 16 but with two button actuators lying adjacent to each other (black/red) and an opening above for a LED

MUGE 19
* black enclosure made of ABS
* lid and base are attached using two studs.
* fastening point for printed circuit

MUGE 20
* black enclosure made of ABS consisting of base and lid
* four countersunk screws seal the housing all around
* four mounting studs for a printed circuit 82x46mm

MUGE 21
* white sensor enclosure made of ABS
* large louvered plates on either side
* fastening points for printed circuit

> More
Showing 1 - 7 of 7 products
  • Product Stock Unit price Volume discounts
  • Supertronic
    MUGE 15
    1,75 €
    17001 MUGE 15 PP012N-S PP012N-S
    1,75 €
    Stock: 575
  • Supertronic
    MUGE 16
    1,37 €
    17008 MUGE 16 PP022NJ-S PP022NJ-S
    1,37 €
    Stock: 3
  • Supertronic
    MUGE 17
    1,58 €
    17009 MUGE 17 PP023N-S PP023N-S
    1,58 €
    Stock: 1216
  • Supertronic
    MUGE 18
    1,46 €
    17010 MUGE 18 PP024NR-S PP024NR-S
    1,46 €
    Stock: 3
  • Supertronic
    MUGE 19
    1,43 €
    17011 MUGE 19 PP040N-S PP040N-S
    1,43 €
    Stock: 1244
  • Supertronic
    MUGE 20
    2,49 €
    17014 MUGE 20 PP041N-S PP041N-S
    2,49 €
    Stock: 514
  • Supertronic
    MUGE 21
    2,29 €
    17015 MUGE 21 PP042W-S PP042W-S
    2,29 €
    Stock: 1413
Showing 1 - 7 of 7 products
