• no reduction in the insulation class resp. the creepage and clearance by plastic retaining clips
• relays are easily replaced
• modules are placed easily and safely (proper polarity alignment) into the socket
• rated voltage: 250V AC
• rated current: 10A
• insulation resistance: 103MΩ
• insulation voltage: 2kV
• type of protection: IP20
• housing material: PA66
• contacts: CuZn33, nickel-plated
DIN rail sockets for 34.51 relays
• snap-on mounting for DIN-rail (EN 50022)
• with screw terminal
• retaining and release clip
• coil indication and EMC suppression modules
• securely disconnection according to the VDE 0106, EN 50178, EN 60204
• for relays with 6...24V DC supply voltage
