S 20 K 250

Epcos metal oxide varistor series SIOV

  • wired and round varistor elements
  • with an epoxy resin coating (UL94V-0)
  • operating temperature: -40 to +85°C
  • pitch: 5 resp. 7,5mm
  • bulk
S 20 K

S 20 K 250

45354 S 20 K 250 B72220S0251K101 B72220S0251K101 Epcos metal oxide varistor series SIOV. wired and round varistor elements with an epoxy resin coating (UL94V-0) operating temperature: -40 to +85°C pitch: 5 resp. 7,5mm bulk

Specifications

manufacturer
Manufacturer's name B72220S0251K101
Current [A] 8000
A [mm] 2,2
(Max.) RMS voltage [V] 250
Operating voltage [V] 320
Varistor voltage at 1mA [V] 390
Supply voltage [V] 650
E [mm] 10
Tolerance of varistor voltage [%] ±10
Capacity [pF] 700
Material strength [mm] 5,3
B [mm] 21,5
L1 [mm] 25
H [mm] 25,5
D [mm] 1
Data Sheet

Unit price

0,252 €

Stock: 1500
Next incoming goods:
CW 15/2026
1000 units

Further delivery:
CW 18/2026

Minimum order quantity 25 units or
multiples of 25.
