85.02 24V

rated current: 7-10A

• multifunction with 4 settings
• monovoltage
• seven over-lapping adjustable time scales from 0,05s to 100h
• setting/operating element with switch adjustable
• LED position indicating device
• solder/plug-in terminals 2x0.5mm
• category of protection IP40
• contact: DPDT
• contact material: AgNi
• rated current: 10A
• max. switching current: 20A
• max. switching voltage: 400V AC
• max. switching power: 2500VA
• recovery time: 20ms
• lifetime electrical: 200x103 operations
• operating temperature: -20...+60°C

85.02 24V

11901 85.02 24V 85.02.0.024.0000 85.02.0.024.0000 rated current: 7-10A. • multifunction with 4 settings• monovoltage• seven over-lapping adjustable time scales from 0,05s to 100h• setting/operating element with switch adjustable• LED position indicating device• solder/plug-in terminals 2x0.5mm• category of protection IP40• contact: DPDT• contact material: AgNi• rated current: 10A• max. switching current: 20A• max. switching voltage: 400V AC• max. switching power: 2500VA• recovery time: 20ms• lifetime electrical: 200x103 operations• operating temperature: -20...+60°C

Specifications

manufacturer
Manufacturer's name 85.02.0.024.0000
Switching current [A] 10
Max. switching power [VA] 2500
Data Sheet

Unit price

40,79 €

Stock: 2
Further delivery:
CW 28/2024
