SBT 01L-09

Mean Well DC/DC converter series SBT01

Unregulated DC/DC converters in an SMD plastic housing with 1W. These low-cost devices are suitable for direct PCB mounting and are protected against short circuit. They have a fanless design and a high reliability. We offer the type SBT 01L-09 of this Mean Well series.

  • single output
  • output: 1W
  • output voltage tolerance: ±8%
  • maximal ripple and noise: 100mVpp
  • withstand voltage: 1000V DC
  • operating temperature: -40 to +85°C
  • weight: 1,3g
Meanwell SBT01 series

SBT 01L-09

30365 SBT 01L-09 SBT01L-09 SBT01L-09 Mean Well DC/DC converter series SBT01. Unregulated DC/DC converters in an SMD plastic housing with 1W. These low-cost devices are suitable for direct PCB mounting and are protected against short circuit. They have a fanless design and a high reliability. We offer the type SBT 01L-09 of this Mean Well series. single output output: 1W output voltage tolerance: ±8% maximal ripple and noise: 100mVpp withstand voltage: 1000V DC operating temperature: -40 to +85°C weight: 1,3g

Specifications

manufacturer
Manufacturer's name SBT01L-09
Case SMD case
Input [V DC] 4,5...5,5
Output current range [mA] 0...111
Output [V] 9
Efficiency [%] 74
Data Sheet

Unit price

3,09 €

Stock: 0
