HDS 15 L

high-density

• solder buckets
• insulating shell: glass fiber reinforced PBT, UL94V-0
• contacts: phosphor bronze
• contact surface: nickel, gold flash plated
• housing frame: steel, tin-plated
• temperature range: -55...+105°C

HDS 15 L

8079 HDS 15 L 598-3-015M-A00TF-BS0 598-3-015M-A00TF-BS0 high-density. • solder buckets• insulating shell: glass fiber reinforced PBT, UL94V-0• contacts: phosphor bronze• contact surface: nickel, gold flash plated• housing frame: steel, tin-plated• temperature range: -55...+105°C

Specifications

manufacturer
Manufacturer's name 598-3-015M-A...
E [mm] 24,99mm
Number of poles 15
A [mm] 30,8
Width [mm] 16,9
E [mm] 24,99
D [mm] 2,29
F [mm] 19,1
C [mm] 0,25

Unit price

0,554 €

Stock: 5792
Further delivery:
CW 40/2024

Minimum order quantity 1 to 2 units or multiples of 10 plus 0 to 2 .
