EEEFT1A102GP

105°C, SMD, low ESR, miniaturized

• SMD electrolytic capacitors
• by Panasonic
• series FT
• taped
• low ESR
• miniaturized
• capacitance tolerance: ±20%
• temperature range: -55°C to +105°C
• operating life (at 105°C): 5000h

SMD-electrolytic capacitors series FT

EEEFT1A102GP

109890 EEEFT1A102GP EEEFT1A102GP 105°C, SMD, low ESR, miniaturized. • SMD electrolytic capacitors• by Panasonic• series FT• taped• low ESR• miniaturized• capacitance tolerance: ±20%• temperature range: -55°C to +105°C• operating life (at 105°C): 5000h

Specifications

manufacturer
Manufacturer's name EEEFT1A102GP
Reverse current [mA] 850
Nominal voltage [V DC] 10
Impedance [Ω] 0,08
Loss factor at 120Hz, 20°C 0,19
Capacity [µF] 1000
Data Sheet

Unit price

0,388 €

Stock: 3000
Further delivery:
CW 40/2024

Minimum order quantity 100 units or
multiples of 100.
