> Passive elements>Capacitors>Electrolytic capacitors>Panasonic electrolytic capacitors, SMD, 105°C, 3000h, TC-V series>EEETC1V470XP

Manufacturers

EEETC1V470XP

SMD electrolytic capacitors series TC-V

We are offering the following capacitors in a taped style by Panasonic: EEETC1A221P, EEETC1A331P, EEETC1A471P, EEETC1C101XP, EEETC1C101P, EEETC1C221P, EEETC1C331P, EEETC1C471P, EEETC1E101P, EEETC1E221P, EEETC1E331P, EEETC1V470XP, EEETC1V470P, EEETC1V101P and EEETC1V221P.

• capacitance tolerance: ±20%
• temperature range: -40°C to +125°C
• operating life (at 125°C): 2000h

SMD-electrolytic capacitors series FKS

EEETC1V470XP

109916 EEETC1V470XP EEETC1V470XP SMD electrolytic capacitors series TC-V. We are offering the following capacitors in a taped style by Panasonic: EEETC1A221P, EEETC1A331P, EEETC1A471P, EEETC1C101XP, EEETC1C101P, EEETC1C221P, EEETC1C331P, EEETC1C471P, EEETC1E101P, EEETC1E221P, EEETC1E331P, EEETC1V470XP, EEETC1V470P, EEETC1V101P and EEETC1V221P. • capacitance tolerance: ±20%• temperature range: -40°C to +125°C• operating life (at 125°C): 2000h

Specifications

manufacturer
Manufacturer's name EEETC1V470XP
Reverse current [mA] 300
Nominal voltage [V DC] 35
Impedance [Ω] 0,45
Loss factor at 120Hz, 20°C 0,16
Data Sheet

Unit price

0,288 €

Stock: 4700
Further delivery:
CW 39/2024

Minimum order quantity 100 units or
multiples of 100.
