> Power supplies>Voltage converters>DC/DC converters, PCB mounting>Recom DC/DC converters, 2W, SIL7 housing, RD series>RD-2405D

Manufacturers

RD-2405D

Recom DC/DC converter series RD

DC/DC converters in a SIL7 housing with 2W, an industry standard pinout and dual output. These devices are suitable for direct PCB mounting, comply with EN60950-1 safety standards and offer continuous short circuit protection (RD_/P types available). We offer various types of this Recom series.

  • dual output
  • output: 2W
  • maximal ripple and noise: 150mVpp
  • operating temperature: -40 to +85°C
  • weight: 2,8g
Recom RD series

RD-2405D

43665 RD-2405D RD-2405D Recom DC/DC converter series RD. DC/DC converters in a SIL7 housing with 2W, an industry standard pinout and dual output. These devices are suitable for direct PCB mounting, comply with EN60950-1 safety standards and offer continuous short circuit protection (RD_/P types available). We offer various types of this Recom series. dual output output: 2W maximal ripple and noise: 150mVpp operating temperature: -40 to +85°C weight: 2,8g

Specifications

manufacturer
Manufacturer's name RD-2405D
Case SIL 7 case
Input voltage [V] 24
Output voltage [V] ±5
Output current range [mA] ±200
Efficiency [%] 75...82
Data Sheet

Unit price

8,79 €

Stock: 25
Next incoming goods:
CW 22/2024
125 units

Further delivery:
CW 38/2024
