T9-611P-4A

in fuseholder-housing, snap-in-mounting

* single pole thermal circuit breaker
* ideal as replacement for fuses, especially for higher rated current
* advantage of being immune to high inrush currents and line transients
* easy snap-in mounting
* for frontpanel with thickness 0.8...2mm
* quick connect terminals 6.3x0.8mm
* rated voltage:
240V AC
48V AC
* conditional short circuit current (PC1, 240V AC): 2000A
* dielectric strenght: 1500V AC
* insulation resistance (500V DC): >100MΩ
* type of tripping: cycling trip-free
* weight: 9g

T9-611P-4A

27455 T9-611P-4A 4404.0001 4404.0001 in fuseholder-housing, snap-in-mounting. * single pole thermal circuit breaker* ideal as replacement for fuses, especially for higher rated current* advantage of being immune to high inrush currents and line transients* easy snap-in mounting* for frontpanel with thickness 0.8...2mm* quick connect terminals 6.3x0.8mm* rated voltage: 240V AC 48V AC* conditional short circuit current (PC1, 240V AC): 2000A* dielectric strenght: 1500V AC* insulation resistance (500V DC): >100MΩ* type of tripping: cycling trip-free * weight: 9g

Specifications

manufacturer
Manufacturer's name 4404.0001
Data Sheet

Unit price

2,19 €

Stock: 151
Further delivery:
CW 07/2025
