BU 405 Ni

panel sockets BU 40 by Schützinger

• CAT I
• series: BU 40_
• all-metal version
• mounting hole Ø 6.1mm
• contacts: brass, Ni-plated
• screw terminal
• max. torque for the fastening nuts: 300Ncm
• max. transition resistance: 10mΩ
• rated current: 32A
• rated voltage: 33V AC / 70V DC
• operating temperature range: -40°C...+110°C
• by Schützinger

BU 405 Ni

43540 BU 405 Ni BU405NI BU405NI panel sockets BU 40 by Schützinger. • CAT I• series: BU 40_• all-metal version• mounting hole Ø 6.1mm• contacts: brass, Ni-plated• screw terminal• max. torque for the fastening nuts: 300Ncm• max. transition resistance: 10mΩ• rated current: 32A• rated voltage: 33V AC / 70V DC• operating temperature range: -40°C...+110°C• by Schützinger

Specifications

manufacturer
Manufacturer's name BU405NI
Rated current 32A
Data Sheet

Unit price

0,77 €

Stock: 50
Further delivery:
CW 51/2024

Minimum order quantity 5 units or
multiples of 5.
