FK 15 L Ni/1 blau

lamella basket plugs FK 15 by Schützinger

* CAT I
* straight
* stackable
* with grip sleeve for Ø 4mm cable, unmounted
* with an axial plug-in socket
* up to 1mm² lead cross-section
* FK 15 L: with solder terminal
* FK 15 S: with screw terminal
* several colours
* contact parts Ni-plated
* insulation: PE (Hostalen)
* max. transition resistance: 3mΩ
* rated current: 16A
* rated voltage: 30V AC/60V DC
* operating temperature range: -25°C...+90°C
* by Schützinger
FK15LNI/1/BL, lamella basket plugs, stackable, 16A

FK 15 L Ni/1 blau

43510 FK 15 L Ni/1 blau FK15LNI/1/BL FK15LNI/1/BL lamella basket plugs FK 15 by Schützinger. * CAT I* straight* stackable* with grip sleeve for Ø 4mm cable, unmounted* with an axial plug-in socket* up to 1mm² lead cross-section* FK 15 L: with solder terminal* FK 15 S: with screw terminal* several colours * contact parts Ni-plated* insulation: PE (Hostalen)* max. transition resistance: 3mΩ* rated current: 16A* rated voltage: 30V AC/60V DC* operating temperature range: -25°C...+90°C* by Schützinger

Specifications

manufacturer
Manufacturer's name FK15LNI/1/BL
Rated current 16A
Colour blue
Data Sheet

Unit price

1,30 €

Stock: 14
Further delivery:
CW 18/2024

Minimum order quantity 5 units or
multiples of 5.
