RKTV 10 VA 2x22 V

toroidal print transformers 10VA by Talema

• power: 10VA
• by Talema
• non short-circuit proof
• primary voltage (50/60Hz): 2x115V AC
• efficiency: 82%
• no-load current, I0typ.: 3mA
• test voltage (prim./sec.): 4kV
• temperature class: T60/E
• temperature rise at rated load: 24K
• protection, 230V, delayed fuse: 80mA
• insulation class: A(105°C): E(125°C)

toroidal print transformators by Talema

RKTV 10 VA 2x22 V

109211 RKTV 10 VA 2x22 V 70045K 70045K toroidal print transformers 10VA by Talema. • power: 10VA• by Talema• non short-circuit proof• primary voltage (50/60Hz): 2x115V AC• efficiency: 82%• no-load current, I0typ.: 3mA• test voltage (prim./sec.): 4kV• temperature class: T60/E• temperature rise at rated load: 24K• protection, 230V, delayed fuse: 80mA• insulation class: A(105°C): E(125°C)

Specifications

manufacturer
Manufacturer's name 70045K
Rated current [mA] 227
Secondary voltage [V] 2x22
Open circuit voltage [V] 2x26,3
Data Sheet

Unit price

16,89 €

Stock: 80
