70003K

Talema toroidal PCB transformers

Toroidal PCB transformers in a fully potted housing with 1,6VA. These transformers are suitable for PCB mounting and are not short-circuit-proof. They have very low iron losses and a high efficiency. We offer the following types of this Talema series: 70000K, 70001K and 70003K.

  • output: 1,6VA
  • primary voltage: 2x115V AC (50/60Hz)
  • no-load current: 1mA
  • temperature resistance: T60/E
  • not short circuit proof
70003K

70003K

38714 70003K 70003K Talema toroidal PCB transformers. Toroidal PCB transformers in a fully potted housing with 1,6VA. These transformers are suitable for PCB mounting and are not short-circuit-proof. They have very low iron losses and a high efficiency. We offer the following types of this Talema series: 70000K, 70001K and 70003K. output: 1,6VA primary voltage: 2x115V AC (50/60Hz) no-load current: 1mA temperature resistance: T60/E not short circuit proof

Discontinued items. Only remainder of stock available.

Specifications

manufacturer
Manufacturer's name 70003K
Rated current [mA] 53
Secondary voltage [V] 2x15
Open circuit voltage [V] 2x19,3
Data Sheet

Unit price

12,49 €

Stock: 6
