RCH 25 2,2 k

thick-film resistors

• by Vishay
• series RCH25
• loose
• compact size
• easy mounting
• high insulation resistance 106MΩ
• tolerance: ±5%
• power rating with heatsink: 25 Watt
• power rating without heatsink: 4W
• operating voltage, max.: 550V
• dielectric strength: 3500V
• operating temperature range: -55 to 125°C
• climatic category: 55/125/56


dimensions

RCH 25 2,2 k

4722 RCH 25 2,2 k RCH25S22000JS06 RCH25S22000JS06 thick-film resistors. • by Vishay• series RCH25• loose• compact size• easy mounting• high insulation resistance 106MΩ• tolerance: ±5%• power rating with heatsink: 25 Watt• power rating without heatsink: 4W• operating voltage, max.: 550V• dielectric strength: 3500V• operating temperature range: -55 to 125°C• climatic category: 55/125/56

Discontinued items. Only remainder of stock available.

Specifications

manufacturer
Manufacturer's name RCH25S22000JS06
Resistance [Ω] 2,2k
Power [W] 4/25
Tolerance [%] 5
Data Sheet

Unit price

10,49 €

Stock: 1
