> Passive elements>Potentiometers>Trimmer potentiometers>Vishay multiturn trimmers, 0,25W, precision trimmers 1/4", T63 series>3266 X 4,7 k

Manufacturers

3266 X 4,7 k

1/4, 0.25 Watt

* vertical
* standard tolerance: ±10%
* resistive element: Cermet
* sealing: IP67
* mechanical travel: 15 ±5
* operating torque, end position: clutch action
* operating torque (max.): 1 Ncm
* weight: 0.5g
3266 X 4,7 k

3266 X 4,7 k

27649 3266 X 4,7 k T63XB472KT20 T63XB472KT20 1/4, 0.25 Watt. * vertical* standard tolerance: ±10%* resistive element: Cermet* sealing: IP67* mechanical travel: 15 ±5* operating torque, end position: clutch action* operating torque (max.): 1 Ncm* weight: 0.5g

Specifications

manufacturer
Manufacturer's name T63XB472KT20
Resistance [Ω] 4,7k
Power, max. [W] 0,25
Transmission current, max. [mA] 7,3
Max. operating voltage [V] 34,2
Data Sheet

Unit price

2,19 €

Stock: 0
Next incoming goods:
CW 33/2026
100 units

Further delivery:
CW 40/2026

Minimum order quantity 10 units or
multiples of 10.
