T7 YA 1 k

Vishay trimmer potentiometers series T7YA

High stability trimmer potentiometers with a low temperature coefficient and easy to read scale. They are only 7mm (0.275”) in diameter and come in a sealed plastic case. We offer various types of this Vishay series.

  • taper: linear
  • power rating (TU = 85°C): 0.5W
  • operating voltage, max.: 250V
  • temperature range: -55 to +125°C
  • protection class: IP64
Vishay series T7 YA

T7 YA 1 k

27619 T7 YA 1 k T7YA102MT20 T7YA102MT20 Vishay trimmer potentiometers series T7YA. High stability trimmer potentiometers with a low temperature coefficient and easy to read scale. They are only 7mm (0.275”) in diameter and come in a sealed plastic case. We offer various types of this Vishay series. taper: linear power rating (TU = 85°C): 0.5W operating voltage, max.: 250V temperature range: -55 to +125°C protection class: IP64

Specifications

manufacturer
Manufacturer's name T7YA102MT20
Resistance [Ω] 1k
Power, max. [W] 0,5
Data Sheet

Unit price

2,09 €

Stock: 419
Further delivery:
CW 10/2026

Minimum order quantity 1 to 19 units or multiples of 25 plus 0 to 19 .
