Mean Well LED driver series PLP-20

LED drivers in an open frame housing with a high reliability, 20W and a universal input. These devices comply with EN61347-1, EN61347-2-13, UL8750, EN55015 as well as EN61000-3-2 Class C and are suitable for LED l...

Mean Well LED driver series PLP-20

LED drivers in an open frame housing with a high reliability, 20W and a universal input. These devices comply with EN61347-1, EN61347-2-13, UL8750, EN55015 as well as EN61000-3-2 Class C and are suitable for LED lighting applications. They are protected against overvoltage, overcurrent, short circuit as well as overtemperature and have a built-in active PFC function. We offer the following types of this Mean Well series: PLP-20-18 and PLP-20-48.

  • single output
  • output: 19,8 to 20,2W
  • input voltage: 90 to 277V AC (47 to 63Hz), 127 to 392V DC
  • maximal input inrush current: 40A
  • withstand voltage I/P-O/P: 3750V AC
  • operating temperature: -30 to +60°C
  • weight: 120g
> More
Data Sheet
Showing 1 - 1 of 1 product
  • Product Stock Unit price Volume discounts
  • Mean Well
    PLP-20-48
    13,69 €
    35756 PLP-20-48 PLP-20-48
    13,69 €

    More
    Stock: 2
Showing 1 - 1 of 1 product
