Mean Well DIN rail power supply series MDR-10

Switching power supplies with 10W, a universal input, a built-in DC OK signal, a low no-load power, an LED indicator for power on and screw terminals. These devices are suitable for DIN rail mounting a...

Mean Well DIN rail power supply series MDR-10

Switching power supplies with 10W, a universal input, a built-in DC OK signal, a low no-load power, an LED indicator for power on and screw terminals. These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have a fanless design and comply with EN62368-1, EN55032 class B, EN61204-3 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: MDR-10-5, MDR-10-12, MDR-10-15 and MDR-10-24.

  • single output
  • output: 10W
  • input voltage: 85 to 264V AC (47 to 63Hz), 120 to 370V DC
  • maximal input inrush current: 70A
  • leakage current: <1mA
  • no-load power: <0,75W
  • overload protection: >105%
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -20 to +70°C
  • weight: 170g
> More
Data Sheet
Showing 1 - 4 of 4 products
  • Product Stock Unit price Volume discounts
  • Mean Well
    MDR-10 5V 2A
    9,39 €
    30716 MDR-10 5V 2A MDR-10-5 MDR-10-5
    9,39 €
    Quantity Unit price
    50 + 8,89 €
    Stock: 545
  • Mean Well
    MDR-10 12V 0,84A
    9,39 €
    30714 MDR-10 12V 0,84A MDR-10-12 MDR-10-12
    9,39 €
    Quantity Unit price
    50 + 8,89 €
    Stock: 122
  • Mean Well
    MDR-10 15V 0,67A
    10,49 €
    30715 MDR-10 15V 0,67A MDR-10-15 MDR-10-15
    10,49 €
    Quantity Unit price
    50 + 9,89 €
    Stock: 88
  • Mean Well
    MDR-10 24V 0,42A
    9,39 €
    30713 MDR-10 24V 0,42A MDR-10-24 MDR-10-24
    9,39 €
    Quantity Unit price
    50 + 8,89 €
    Stock: 871
Showing 1 - 4 of 4 products
