CRC Kontakt Chemie protective coating for PCBs

The electric isolation of PCBs is at risk due to moisture, industrial dust particals or corrosive atmosphere. The CRC PCB lacquer contains high leakage current and dielectric strength and is used for the protection of PCBs.

acryl lacquer, transpare...

The electric isolation of PCBs is at risk due to moisture, industrial dust particals or corrosive atmosphere. The CRC PCB lacquer contains high leakage current and dielectric strength and is used for the protection of PCBs.

acryl lacquer, transparent K70 400 ml
* universal insulating lacquer for multiple use
* quick drying, colourless transparent, flexible, UV light resistant
* protects PCBs and surfaces against humid anorganic-acid or caustic vapours
* low viscosity, solvent drying acrylic based lacquer
* drying time at 20°C: 15...20 mins.
* durable adhesion in temperature ranges between -40...+ 60°C, short period temperature capacity at 100°C (max. 0,5h)
* dielectric strength >80kV/mm
* directly solderable for repair purposes

acrylic resin lacquer K 70 super
* protective and insulating lacquer for highest demands
* colorless acrylic resin lacquer combines fast dry time with maximum protection and insulation
* prevents leakage current
* provides reliable long-term protection against dirt, moisture, corrosive fumes and changing weather conditions.
* wide temperature range: -40 ... +125°C
* hardens quickly
* UV tracer: inspect the area coverage

polyurethane-alkyd resin coating, transparent K71
* increased protection in aggressive environments
* air drying one-component polyurethane-alkyd resin coating
* protects against humidity, soluble vapours, petrol
* drying time at 20°C: dry to touch in 20 mins., curing: 2...7 days
* temperature range: -40...+120°C
* dielectric strength: approx. 130kV/mm
* directly solderable for repair purposes

> More
Showing 1 - 6 of 6 products
  • Product Stock Unit price Volume discounts
  • CRC Kontakt Chemie
    1035373, CRC Kontakt Chemie protective coating for PCBs
    11,09 €
    1276 K70 200 ml 1035373 1035373
    11,09 €
    Stock: 51
  • CRC Kontakt Chemie
    1035379, CRC Kontakt Chemie protective coating for PCBs
    15,99 €
    1277 K70 400 ml 1035379 1035379
    15,99 €
    Stock: 64
  • CRC Kontakt Chemie
    1035381, CRC Kontakt Chemie protective coating for PCBs
    27,59 €
    245326 K 70 1 Liter 1035381 1035381
    27,59 €
    Stock: 5
  • CRC Kontakt Chemie
    K70 Super 400 ml
    18,59 €
    44333 K70 Super 400 ml 1031249 1031249
    18,59 €
    Stock: 17
  • CRC Kontakt Chemie
    75009-AE, CRC Kontakt Chemie protective coating for PCBs
    12,09 €
    1279 K71 200 ml 1035395 1035395
    12,09 €
    Stock: 11
  • CRC Kontakt Chemie
    K71 400 ml
    19,19 €
    1280 K71 400 ml 1035398 1035398
    19,19 €
    Stock: 26
