> Passive elements>Terminals>Terminal blocks>PTR terminal blocks, pitch 5mm, 17,5A, screw-cage clamp principle, AK350 series>AK 350/06-5,0-V

Manufacturers

AK 350/06-5,0-V

PTR terminal block series AK350

  • screw-cage clamp principle
  • side wire entry
  • 2-, 3-, 4-, 5- or 6-pole
  • pitch: 5mm
  • rated voltage (EN 60998): 250V
  • rated current (T60): 17,5A
  • test voltage: 2kV
  • rated cross section single-stranded wire: 2.5mm²
  • rated cross section fine-stranded wire: 1.5mm²
  • stripped length: 6mm
  • insulating material: PA
  • temperature range: -30 to +105°C
  • flammability class: UL94V-0
  • colour: green
PTR terminal blocks

AK 350/06-5,0-V

112438 AK 350/06-5,0-V AK350/6-5.0-V-GRÜN AK350/6-5.0-V-GRÜN PTR terminal block series AK350. screw-cage clamp principle side wire entry 2-, 3-, 4-, 5- or 6-pole pitch: 5mm rated voltage (EN 60998): 250V rated current (T60): 17,5A test voltage: 2kV rated cross section single-stranded wire: 2.5mm² rated cross section fine-stranded wire: 1.5mm² stripped length: 6mm insulating material: PA temperature range: -30 to +105°C flammability class: UL94V-0 colour: green

Specifications

manufacturer
Manufacturer's name AK350/6-5.0-V-GRÜN
Design screw-cage...
Number of poles 6
Height [mm] 13,5
Pitch [mm] 5
T [mm] 9
Length [mm] 30,6
Data Sheet

Unit price

0,876 €

Stock: 0
Next incoming goods:
CW 03/2026
100 units

Further delivery:
CW 05/2026

Minimum order quantity 50 units or
multiples of 50.
