LED switching power supply NPF-40D by Meanwell

These switching power supplies have a constant current, a low no-load power as well as a fixed output voltage and are suitable for LED and illumination applications (indoor/outdoor). The devices are d...

LED switching power supply NPF-40D by Meanwell

These switching power supplies have a constant current, a low no-load power as well as a fixed output voltage and are suitable for LED and illumination applications (indoor/outdoor). The devices are dimmable (external voltage 1 to 10 volt DC, PWM, potentiometer). Endued with universal AC input and built-in PFC function, plastic enclosure (IP67) and are protected against short circuit, overvoltage and overload by current limitation (auto recovery). We offer the following types by manufacturer Mean Well: NPF-40D-12, NPF-40D-15, NPF-40D-20, NPF-40D-24, NPF-40D-30, NPF-40D-36, NPF-40D-42, NPF-40D-48 und NPF-40D-54

* output: 40 Watt
* input voltage: 127 to 431 V DC, 90 to 305 V AC (47 to 63Hz)
* output constant current range: 60 to 100%
* maximal input inrush current: 50A
* maximal no load power consumption: 0.5W
* 95 to 108% overcurrent protection
* I/P-O/P, withstand voltage: 3750 V AC
* operating temperature: -40 to +70°C
* by Meanwell
* weight: 0.49 kg

> More
Download

Showing 1 - 9 of 9 items
  • article stock price volume discount
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45584 NPF-40D-12 NPF-40D-12
    21,30 €
    20 pcs. / 18,80 €
    stock: 32
  • MeanWell
    F
    21,30 €
    104787 NPF-40D-15 NPF-40D-15
    21,30 €
    20 pcs. / 18,80 €
    stock: 89
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45585 NPF-40D-20 NPF-40D-20
    21,30 €
    20 pcs. / 18,80 €
    stock: 34
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45586 NPF-40D-24 NPF-40D-24
    21,30 €
    20 pcs. / 18,80 €
    stock: 100
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45587 NPF-40D-30 NPF-40D-30
    21,30 €
    20 pcs. / 18,80 €
    stock: 69
  • MeanWell
    NPF-40D-36
    21,30 €
    45588 NPF-40D-36 NPF-40D-36
    21,30 €
    20 pcs. / 18,80 €
    stock: 28
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45589 NPF-40D-42 NPF-40D-42
    21,30 €
    20 pcs. / 18,80 €
    stock: 27
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45590 NPF-40D-48 NPF-40D-48
    21,30 €
    20 pcs. / 18,80 €
    stock: 20
  • MeanWell
    Meanwell NPF-40D series
    21,30 €
    45591 NPF-40D-54 NPF-40D-54
    21,30 €
    20 pcs. / 18,80 €
    stock: 9
Showing 1 - 9 of 9 items
